Gas Tanker Semi Trailer
- Volume:
2 axles :20000L-40000L
3 axles:35000L-70000L
- Material: Carbon steel/Stainless steel/Alloy
- Usage: Fuel oil transporting
- Size:
2 axles :10080*2500*3600 (mm) (Other dimensions optional)
3 axles:11980*2500*3800 (mm) (Other dimensions optional)
- Tank body: 5mm
- End plate: 6mm
- Manhole: 500mm
- Discharge valve: Ball valve
- Discharge pipe: 4'' rubber hose
- Overview
- Recommended Products
Tank trailer is a type of semi-trailer designed to transport liquids, gases, or dry bulk materials. These trailers are commonly used in industries such as petroleum, chemicals, food & beverage, and agriculture.
Tanker Types & Applications
Type |
Capacity Range |
Common Loads |
Special Features |
Fuel Tanker |
5,000-11,600gal |
Gasoline, diesel, jet fuel |
Compartmentalized (2-7 tanks) |
Chemical Tanker |
6,000-9,000gal |
Acids, solvents, hazmat |
Stainless steel, vapor recovery |
Food Grade |
5,500-8,500gal |
Milk, oils, liquid chocolate |
FDA-approved polished interior |
Cryogenic |
4,000-6,500gal |
LNG, liquid nitrogen |
Vacuum-insulated (-320°F cap.) |
Dry Bulk |
1,500-3,000cu.ft |
Cement, flour, plastic pellets |
Pneumatic unloading system |
Specifications and Parameters:
Volume |
2 axles :20000L-40000L 3 axles:35000L-70000L |
Material |
Carbon steel/Stainless steel/Alloy |
Usage |
Fuel oil transporting |
Size |
2 axles :10080*2500*3600 (mm) (Other dimensions optional) 3 axles:11980*2500*3800 (mm) (Other dimensions optional) |
Tank body |
5mm |
End plate |
6mm |
Manhole |
500mm |
Discharge valve |
Ball valve |
Discharge pipe |
4’’ rubber hose |
Axles |
2 axles :2 * 13ton capacity (Brand optional) 3 axles:3 * 13ton capacity (Brand optional) |
Suspension |
Mechanical suspension (Air suspension optional) |
Leaf spring |
10pcs |
Tire |
2 axles :12R22.5 8pcs (Other size optional) 3 axles:12R22.5 12pcs (Other size optional) |
Rim |
2 axles :9.00-22.5 8pcs (Other size optional) 3 axles:9.00-22.5 12pcs (Other size optional) |
Kin pin |
2’’/3.5’’ bolt type |
Landing gear |
28 Ton two speed |
Braking system |
Double air chamber ,brake valve,40L air tanks ;ABS optional |
Electrical |
LED light , 7 ways ,24V |
Painting |
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting |
Frequently Asked Questions (FAQ):
Q: Does your company has your own factory?
A: Yes,we have a factory ourself,which is in this business for few years in China.Our factory is very famous where is manufacturing various trailers in Shan Dong,China.
Q: What is your minimum order quantity?
A: One unit
Q: Can you satisfy my special requirement?
A: Definitely!We can make the trailers based on your requirement.
Q: What logistics methods can you use for transportation?
A: We can use various transportation tools to transport construction machinery.
(1) Our main mode of transportation is that the machine will be shipped by container or ro-ro/bulk.
(2) For China's inland neighboring countries, we can ship the machine by road or rail.
(3) For urgently needed spare parts, we can ship by DHL, TNT, UPS or FEDEX.
Q: Do you have any other services?
A: Our company's aim is to give you satisfaction, our services include the best price, shipping and packaging, booking the cargo hold, and helping you buy parts.
